7x50/PRD/A Series

Professional All weatherproof Binoculars with Build-in Illuminated compass, Retile and Distance calculator

-

Bak4 glass porro prisms and All glass optics

-

Fully coated optics

-

Fibreglass reinforced Polycarbonate body provide Rigid and Light weight construction

-

Ribbed rubber grips for easy holding

-

Built-in Illuminated compass and Reticle and Distance calculator

-

150(H)x 200(W)x 76(D)mm (dimension)

-

1050g (weight)

-

Without Compass model 7x50/WP available

Weatherproof Series

Sturdy rubber armoured Weatherproof binoculars are ideal for tough and inclement viewing conditions. Centre focusing wheel plus right eyepiece adjustment.

-

10x Magnification with 50mm Objective diameter
7x35 model
8x40 model
7x50 model available

-

+2 to -2 diopters adjustment

-

Glass porro prisms with Hybrid optics

-

Fully coated optics available in Green, Amber or Clear. (Ruby coating available as extra)

-

Die cast aluminium body construction

-

Water resistant rubber armour in black, green or camouflage colour with folding rubber eyecups

-

180(H)x 194(W)x 70(D)mm (dimension)

-

870g (weight)

Metal Body Series

Metal bodied ZCF binoculars offered in traditional Leatherette finish or Smooth rubber contoured design. Oversized focus wheel provides Easier and Quicker focusing

-

10x Magnification with 50mm Objective diameter
7x35 model
8x30 model
8x40 model
12x50 model
16x50 model
20x50 model available

-

+2 to -2 diopters adjustment

-

Glass porro prisms with Hybrid optics

-

Semi coated optics (Ruby Coating available)

-

Die cast aluminium body construction

-

Available in PVC leatherette, leather grain or diamond cut with fold down rubber eyecups

-

161(H)x 192(W)x 66(D)mm (dimension)

-

870g (weight)

Fibreglass Series

Modern economical design incorporated in Lightweight and unique body contruction with Centre focusing wheel plus Right eyepiece adjustment

-

20x Magnification with 50mm Objective diameter
7x35/NP available
7x50/NP available
8x30/NP available
8x40/NP available
10x50/NP available
12x50/NP available
16x50/NP available

-

+2 to -2 diopters with click stops adjustment

-

Glass porro prisms with Hybrid optics

-

Fully coated optics

-

Fibreglass reinforced ABS body

-

170(H)x 205(W)x 70(D)mm (dimension)

-

798g (weight)

Sports Series

Focus free binoculars is ideal for Sporting events where the Fast action leaves no time for manual focusing

-

7x Magnification with 50mm Objective diameter
7x35 model
8X40 model
10X50 model available

-

Glass porro prisms with Hybrid optics

-

Hybrid coated optics available in Green, Amber or Clear (Ruby coating available as extra)

-

Die cast aluminium body construction

-

Available in smooth rubber with fold down rubber eyecups

-

173(H)x 194(W)x 66(D)mm (dimension)

-

800g (weight)

Splashproof Series

Perfect Binoculars for Outdoor pursuits. Light weight and Rubber-gripped plus fully Sealed with O-rings

-

10x Magnification with 40mm Objective diameter
8x32/SP model available

-

+2 to -2 diopters adjustment

-

Glass porro prisms with hybrid optics

-

Fully coated optics
Colour multi-coating (optional)

-

Fibreglass reinforced plastic body with o-rings inside to seal joining parts

-

Rubber hand grip and Folding rubber eyecups

-

163(H)x 180(W)x 55(D)mm (dimension)

-

550g (weight)

E Series

Modern, Compact and Light weight design with Rubber-gripped covering plus Center focusing wheel

-

8x Magnification with 32mm Objective diameter
7x35/E model
8x40/E model
10x40/E model available

-

+2 to -2 diopters adjustment

-

Glass porro prisms with hybrid optics

-

Hybrid coated optics

-

Fibreglass reinforced plastic body

-

Rubber hand grip and Folding rubber eyecups

-

130(H)x 170(W)x 53(D)mm (dimension)

-

366g (weight)

Compact 2x Zoom Series

7x to 15x Magnification Compact Zoom design with Centre focusing wheel plus Left eyepiece adjustment and Right eyepiece zoom lever

-

25mm Objective diameter

-

+2 to -2 diopters adjustment

-

Reverse porro prisms with Hybrid glass optics

-

Semi coated optics
Color multi-coating (optional)

-

Fibreglass reinforced plastic body

-

106(H)x 112(W)x 52(D)mm (dimension)

Compact Series

Crisp, Clear images in Affordable Compact design with Centre focusing wheel plus left Eyepiece adjustment

-

8x Magnification with 25mm Objective diameter
7x25 model available
10x25 model available

-

+2 to -2 diopters abjustment

-

Reverse porro prisms with all glass optics

-

Semi coated optics Color multi-coating (optional)

-

Fibreglass reinforced plastic body

-

100(H)x 112(W)x 52(D)mm (dimension)

Mini Series

Ultra compact and stylish model for you carrying everywhere. Central focusing mechanism with right eyepiece adjustment.

-

8x Magnification
7x model
10x model available

-

21mm Objective diameter

-

+2 to -2 diopters adjustment

-

BK7 Glass Porro prisms
Hybrid optics
All-glass optics (optional)

-

Semi coated
Fully coated (optional)
Color multi-coating (optional)

-

Fibreglass reinforced plastic body

-

75(H) x 101(W) x 40(D)mm (dimension)

-

138g (weight)
