ZMAE1900 Series


Full features compact 3x zoom camera
for 35mm film with marco mode

@

-

28mm-85mm, 5 element hybrid zoom lens with motorised control

-

Active infra red auto focus system (8 zones) with additional infinity focus mode, close focus mode and focus lock

-

Real image zooming optical viewfinder

-

Full function LCD displays frame number, flash mode (auto flash, fill flash & flash off), red eye reduction mode and focus mode

-

Self timer (10 seconds duration with blinking LED indicator)

-

117 x 64 x 45.2mm (dimension)

-

1 x CR2 Lithium battery (power source)

-

Optional Databack

@

ZMAE1800 Series


Full features compact 2.5x Zoom camera for 35mm film with Motorised control

@

-

Active infra red auto focus system (8 zones) with additional Infinity focus mode, Marco mode and Focus lock

-

Real image Zooming optical viewfinder

-

Full function LCD displays frame number, flash mode (auto flash, fill flash, flash off), Red eye reduction mode and focus mode

-

Self timer (10 seconds duration with blinking LED) indicator

-

117(W) x 64(H) x 42(D)mm (dimension)

-

Auto battery shut off & Self-timer

-

Data back (optional)



@

ZMAE1700 Series


35mm Auto focus 2x zoom camera, Motor wind, Auto sensor flash with Red eye reduction and LCD display

@

-

35mm-70mm (2x zoom ratio) 4 groups 5 elements hybrid zoom lens with Motorised control

-

5 zones active infra red Auto focus system with Focus lock

-

Reverse Galilean Zooming optical viewfinder

-

Full function LCD displays frame number, Flash mode ( auto flash, fill flash, flash off ), Red eye reduction mode.

-

Electronic sensor flash with high intensity Tungsten bulb to reduce Red-eye effect; ISO 100/21X Guide Number of 8m (26 feet); Auto sensor flash is coupled to the DX system to give correct flash actuation for each film speed

-

123(W) x 69(H) x 48(D)mm (dimension)

-

1x CR123A Lithium battery

-

Auto battery shut off & Self-timer

-

Data back (optional)

@

ZMAE1600 Series


Ultra compact Auto focus motor zoom camera for 35mm film

@

-

38mm-65mm Zoom lens with Motorised control

-

Four zones active infra red Auto focus system with Focus lock

-

Real image Zooming optical viewfinder

-

LCD displays Frame number, Flash mode (Auto flash, Fill flash) and Red eye reduction mode

-

117.5(W) x 65(H) x 38.2(D)mm (dimension)

-

1x CR123A Lithium battery

-

Data back (optional)

@

ZMAE1400 Series


Auto focus Wide angle 2x Zoom camera, Motor wind, Auto sensor flash and LCD display

@

-

28mm-56mm (2x zoom ratio) hybrid zoom lens with Motorised control

-

4 zone Active infra red auto focus system with additional Infinity focus mode and Focus lock

-

Full function LCD displays Frame number, Flash mode (auto flash, fill flash, flash off), Self timer mode and Focus mode

-

123(W) x 70(H) x 47(D)mm (dimension)

-

1x CR123A Lithium battery

-

Data back (optional)

@

@

ZME1350 Series


Compact 35mm Zoom camera with Motor zoom control, LCD Display, and Auto sensor flash with Self timer

@

-

28mm-54mm (1.9x zoom ratio) Zoom lens with Motor zoom control

-

Automatic motor advance; automatic rewind at film end with mid roll rewind switch

-

LCD displays frame number, flash mode, Red eye reduction mode and Self timer mode

-

Auto sensor flash; Redeye reduction High intensity tungsten bulb; flash off; daylight fill flash

-

123(W) x 69(H) x 48(D)mm (dimension)

-

Data back (optional)

@

ZME1300/LCD Series


Motor wind 35mm Focus free Zoom camera with Motor zoom control, DX film sensing, Auto sensor flash with Red-eye reduction and LCD display

@

-

28mm-52mm (1.8 x zoom ratio) 4 element hybrid zoom lens with motor zoom control

-

Zooming optical viewfinder

-

LCD displays frame number and flash ready status

-

123(W) x 69(H) x 48(D)mm (dimension)

-

1x CR123A Lithium battery

-

Auto battery shut off, Self-timer & Tripod socket

-

Data back (optional)

@

HMAE280 Series


"Slimline" Autofocus motor camera with Auto sensor flash, DX film sensing, Red-eye reduction, Mid-roll panoramic format switch and LCD Control Panel

@

-

29mm f/4.5 - 3 element Hybrid lens

(28mm f/6 Plastic lens is optional)

(28mm f/4.5 Glass lens is optional)

-

Dual film formats are selectable at any time.

Normal Mode: 24x36mm

Panoramic: 13x36mm

-

Reverse - Galilean with panoramic masking in Panoramic mode and control for 1 Diopter adjustment by user.

-

LCD displays frame number and flash ready status.

-

Self timer (10 second delay with blinking LED indicator)

-

Data back (optional)

-

Focus free HME280 Series available

@

@

@

HMAE190 Series


35mm Compact Big viewfinder Motor wind camera with Auto focus, Self timer, Auto sensor flash, Autoload to frame 1, rapid flash charging, DX and Red eye reduction.

@

-

28mm f4.5 - hybrid lens (28mm f/4.5 - 3 element glass lens is optional)

-

Large sized reverse-Galilean viewfinder

-

LCD display panel with Self timer

-

2 steps for ISO 100/200 and ISO 400 film

-

Electronic sensor flash with high intensity LED to reduce Red-eye effect; Auto sensor flash is coupled to the DX system to give correct flash actuation for each film speed

-

110(W) x 68.8(H) x 40(D) mm (dimension)

-

2 x AA - size alkaline battery

-

Auto battery shut off

-

Daylight fill flash

-

Data back (optional)

@

@

HMAE180 Series


35mm Compact, Big viewfinder, Motor wind camera with Autofocus, Auto sensor flash, DX and Red eye reduction

@

-

28mm f/4.5 - hybrid lens

-

Large sized reverse-Galilean viewfinder

-

Electronic sensor flash with high intensity LED to reduce red-eye effect; Auto sensor flash is coupled to the DX system to give correct flash actuation for each film speed

-

110(w) x 68.8(H) x 40(D) mm (dimension)

-

2 x AA - size alkaline battery

-

Auto battery shut off

-

Daylight fill flash

-

Fixed focus HME180 Series available

-

Data back (optional)

@

@

HME1090 Series


35mm Big Viewfinder fixed focus Motor wind camera

@

-

28mm f/5.6 - 3 element plastic lens

-

Auto Sensor flash

-

Large sized viewfinder for ease of use

-

Automatic motor advance

-

Automatic rewind actuated by rewind switch

-

120.5(W) x 70.5(H) x 40(D) mm (dimension)

-

2 x AA - size alkaline battery

-

Auto battery shut-off

-

Manual flash MH1090 Series available

@

HME150 Series


Economical Motor wind 35mm camera with Auto electronic flash and Red-eye reduction

@

-

28mm f/9.5 - 2 element plastic lens

-

Large sized viewfinder for ease of use

-

Automatic motor film advance

-

Motor rewind actuated by rewind switch

-

2 x AA - size alkaline batteries

-

129.5(W) x 77(H) x 40.7(D) mm (dimension)

-

Manual flash HM150 Series available

@

HF100 Series


Economical manual wind 35mm camera with built-in electronic flash

@

-

35mm f/9.5 plastic lens

-

Large sized viewfinder for ease to use

-

Easy loading system

-

Manual thumb-wheel advance; manual rewind crank

-

Electronic flash with ISO 100/21X Guide Number of 28 feet (8.5m); Manual ON/OFF switch

-

2 x AA - size Alkaline batteries

-

124(W) x 70.5(H) x 40(D) mm (dimension)

@

HP120 Series


Compact Dual Format 35mm camera with Built-in electronic flash and Red-Eye Reduction

@

-

Switchable at any time between standard 24x36mm format and PANORAMIC 13x36mm format

-

28mm f/9.5 - 2 element plastic lens

-

Reverse V Galilean. Viewfinder mask changes automatically to show correct field of view for film format selected

-

Easy loading system

-

Manual thumb-wheel advance; Manual rewind crank

-

Electronic flash with High Intensity LED illuminates before each flash picture to reduce Red-Eye

-

2 x AAA - size alkaline batteries

-

104.5(W) x 62(H) x 37.5(D)mm (dimension)


Specification and equipment are subject to be changed without any notice or obligation on the part of the manufacturer
