ZMAE1900 Series

Full features compact 3x zoom camera for 35mm film with marco mode

-

28mm-85mm, 5 element hybrid zoom lens with motorised control

-

Active infra red auto focus system (8 zones) with additional infinity focus mode, close focus mode and focus lock

-

Real image zooming optical viewfinder

-

Full function LCD displays frame number, flash mode (auto flash, fill flash & flash off), red eye reduction mode and focus mode

-

Self timer (10 seconds duration with blinking LED indicator)

-

117 x 64 x 45.2mm (dimension)

-

1 x CR2 Lithium battery (power source)

-

Optional Databack

ZMAE1700 Series

35mm Auto focus 2x zoom camera, Motor wind, Auto sensor flash with Red eye reduction and LCD display

-

35mm-70mm (2x zoom ratio) 4 groups 5 elements hybrid zoom lens with Motorised control

-

5 zones active infra red Auto focus system with Focus lock

-

Reverse Galilean Zooming optical viewfinder

-

Full function LCD displays frame number, Flash mode ( auto flash, fill flash, flash off ), Red eye reduction mode.

-

Electronic sensor flash with high intensity Tungsten bulb to reduce Red-eye effect; ISO 100/21° Guide Number of 8m (26 feet); Auto sensor flash is coupled to the DX system to give correct flash actuation for each film speed

-

123(W) x 69(H) x 48(D)mm (dimension)

-

1x CR123A Lithium battery

-

Auto battery shut off & Self-timer

-

Data back (optional)

ZMAE1600 Series

Ultra compact Auto focus motor zoom camera for 35mm film

-

38mm-65mm Zoom lens with Motorised control

-

Four zones active infra red Auto focus system with Focus lock

-

Real image Zooming optical viewfinder

-

LCD displays Frame number, Flash mode (Auto flash, Fill flash) and Red eye reduction mode

-

117.5(W) x 65(H) x 38.2(D)mm (dimension)

-

1x CR123A Lithium battery

-

Data back (optional)

ZMAE1400 Series

Auto focus Wide angle 2x Zoom camera, Motor wind, Auto sensor flash and LCD display

-

28mm-56mm (2x zoom ratio) hybrid zoom lens with Motorised control

-

4 zone Active infra red auto focus system with additional Infinity focus mode and Focus lock

-

Full function LCD displays Frame number, Flash mode (auto flash, fill flash, flash off), Self timer mode and Focus mode

-

123(W) x 70(H) x 47(D)mm (dimension)

-

1x CR123A Lithium battery

-

Data back (optional)

ZME1350 Series

Compact 35mm Zoom camera with Motor zoom control, LCD Display, and Auto sensor flash with Self timer

-

28mm-54mm (1.9x zoom ratio) Zoom lens with Motor zoom control

-

Automatic motor advance; automatic rewind at film end with mid roll rewind switch

-

LCD displays frame number, flash mode, Red eye reduction mode and Self timer mode

-

Auto sensor flash; Redeye reduction High intensity tungsten bulb; flash off; daylight fill flash

-

123(W) x 69(H) x 48(D)mm (dimension)

-

Data back (optional)

ZME1300/LCD Series

Motor wind 35mm Focus free Zoom camera with Motor zoom control, DX film sensing, Auto sensor flash with Red-eye reduction and LCD display

-

28mm-52mm (1.8 x zoom ratio) 4 element hybrid zoom lens with motor zoom control

-

Zooming optical viewfinder

-

LCD displays frame number and flash ready status

-

123(W) x 69(H) x 48(D)mm (dimension)

-

1x CR123A Lithium battery

-

Auto battery shut off, Self-timer & Tripod socket

-

Data back (optional)

HMAE280 Series

"Slimline" Autofocus motor camera with Auto sensor flash, DX film sensing, Red-eye reduction, Mid-roll panoramic format switch and LCD Control Panel

-

29mm f/4.5 - 3 element Hybrid lens

(28mm f/6 Plastic lens is optional)

(28mm f/4.5 Glass lens is optional)

-

Dual film formats are selectable at any time.

Normal Mode: 24x36mm

Panoramic: 13x36mm

-

Reverse - Galilean with panoramic masking in Panoramic mode and control for ±1 Diopter adjustment by user.

-

LCD displays frame number and flash ready status.

-

Self timer (10 second delay with blinking LED indicator)

-

Data back (optional)

-

Focus free HME280 Series available

HMAE190 Series

35mm Compact Big viewfinder Motor wind camera with Auto focus, Self timer, Auto sensor flash, Autoload to frame 1, rapid flash charging, DX and Red eye reduction.

-

28mm f4.5 - hybrid lens (28mm f/4.5 - 3 element glass lens is optional)

-

Large sized reverse-Galilean viewfinder

-

LCD display panel with Self timer

-

2 steps for ISO 100/200 and ISO 400 film

-

Electronic sensor flash with high intensity LED to reduce Red-eye effect; Auto sensor flash is coupled to the DX system to give correct flash actuation for each film speed

-

110(W) x 68.8(H) x 40(D) mm (dimension)

-

2 x AA - size alkaline battery

-

Auto battery shut off

-

Daylight fill flash

-

Data back (optional)

HMAE180 Series

35mm Compact, Big viewfinder, Motor wind camera with Autofocus, Auto sensor flash, DX and Red eye reduction

-

28mm f/4.5 - hybrid lens

-

Large sized reverse-Galilean viewfinder

-

Electronic sensor flash with high intensity LED to reduce red-eye effect; Auto sensor flash is coupled to the DX system to give correct flash actuation for each film speed

-

110(w) x 68.8(H) x 40(D) mm (dimension)

-

2 x AA - size alkaline battery

-

Auto battery shut off

-

Daylight fill flash

-

Fixed focus HME180 Series available

-

Data back (optional)

HME1090 Series

35mm Big Viewfinder fixed focus Motor wind camera

-

28mm f/5.6 - 3 element plastic lens

-

Auto Sensor flash

-

Large sized viewfinder for ease of use

-

Automatic motor advance

-

Automatic rewind actuated by rewind switch

-

120.5(W) x 70.5(H) x 40(D) mm (dimension)

-

2 x AA - size alkaline battery

-

Auto battery shut-off

-

Manual flash MH1090 Series available

HME150 Series

Economical Motor wind 35mm camera with Auto electronic flash and Red-eye reduction

-

28mm f/9.5 - 2 element plastic lens

-

Large sized viewfinder for ease of use

-

Automatic motor film advance

-

Motor rewind actuated by rewind switch

-

2 x AA - size alkaline batteries

-

129.5(W) x 77(H) x 40.7(D) mm (dimension)

-

Manual flash HM150 Series available

HF100 Series

Economical manual wind 35mm camera with built-in electronic flash

-

35mm f/9.5 plastic lens

-

Large sized viewfinder for ease to use

-

Easy loading system

-

Manual thumb-wheel advance; manual rewind crank

-

Electronic flash with ISO 100/21° Guide Number of 28 feet (8.5m); Manual ON/OFF switch

-

2 x AA - size Alkaline batteries

-

124(W) x 70.5(H) x 40(D) mm (dimension)

HP120 Series

Compact Dual Format 35mm camera with Built-in electronic flash and Red-Eye Reduction

-

Switchable at any time between standard 24x36mm format and PANORAMIC 13x36mm format

-

28mm f/9.5 - 2 element plastic lens

-

Reverse – Galilean. Viewfinder mask changes automatically to show correct field of view for film format selected

-

Easy loading system

-

Manual thumb-wheel advance; Manual rewind crank

-

Electronic flash with High Intensity LED illuminates before each flash picture to reduce Red-Eye

-

2 x AAA - size alkaline batteries

-

104.5(W) x 62(H) x 37.5(D)mm (dimension)
